Published Jun 13. 2014 - 1 year ago

Fly Tying Thread Table

Manufacturers, materials, diameters, breaking strengths and much more for a large number of fly-tying threads

This table tries to summarize all available data on all current (and some discontinued) fly-tying threads and accompanies the article on the subject of tying threads.
Much of the information presented here has been compiled from whatever data was available from the different manufacturers and their distributors and dealers as well as some independent sources. Care has been taken to double check everything, and whenever there were different specs on a thread, I have taken the one that gave the most benefit to it - not that this is necessarily right, but to be fair and let the doubt benefit the manufacturer. Many manufacturers don't specify the physical properties of their threads - like thickness, Denier, breaking strength, material or production method. Some are very secretive and some simply don't have the information commonly available. The various columns are explained below the table.

Tying thread table

Click the headers to sort. 97 tying threads listed

Brand Product Material Aught Denier Dia
(mm)
Test
(grams)
Denier
per mm
Absolute
strength
Relative
dia
Relative
strength
Flat-
ability
Split-
ability
Smooth-
ness
Benecchi Super/Ultra Strong GSP 10/0 50 0.033 1077 1515 Strong
Strong high good smooth
Benecchi Ultrafine 12/0 Polyester 12/0 70 0.048 450 1458 Average
Below average
Benecchi Superfine 10/0 Polyester 10/0 120 0.051 680 2353 Average
Average
Benecchi Fine 8/0 Polyester 8/0 150 0.056 822 2679 Strong
Average
Benecchi Ghost Thread Mono   60 0.076 312 789 Weak
Weak none none very smooth
Danville Flymaster Plus 140 Nylon   140 0.046 907 3043 Strong
Above average
Danville Flat Waxed Nylon Nylon   210 0.051 1304 4118 Very strong
Strong
Danville Flymaster Plus 210 Nylon   210 0.071 1360 2958 Very strong
Above average
Danville Flymaster 6/0 Nylon 6/0 70 0.038 312 1842 Weak
Below average
Danville Spiderweb Mono 16/0 30 0.051 142 588 Very weak
Very weak none none very smooth
Danville Monocord Nylon 3/0 116 0.066 737 1758 Strong
Average medium possible neutral
Danville Monofilament Ultra Fine Mono     0.102
  none none very smooth
Danville Monofilament Fine Mono     0.152
  none none very smooth
Gordon Griffiths Cobweb Polyester 6/0 134 0.104 1900 1288 Very strong
Above average
Gordon Griffiths Sheer Polyester 14/0 72 0.046 450 1565 Average
Below average
Gordon Griffiths Wisp Polyester 8/0 108 0.056 425 1929 Average
Below average
Gudebrod 6/0 Mono Mono 6/0 131 0.152   862
  none none very smooth
Gudebrod 3/0 Polyester 3/0 176 0.102 1077 1725 Strong
Average
Gudebrod G Mono   210 0.178 1559 1180 Very strong
Below average none none very smooth
Gudebrod G Polyester   330 0.089 1673 3708 Very strong
Above average
Gudebrod Kevlar Kevlar 3/0 115 0.089   1292
  medium difficult coarse
Gudebrod 10/0 Polyester 10/0 45 0.025 255 1800 Weak
Below average medium possible neutral
Gudebrod GX1 GSP   70 0.025 2523 2800 Extremely strong
Extremely strong high good smooth
Gudebrod GX2 GSP   130 0.042   3095
  high good smooth
Gudebrod 8/0 Polyester 8/0 67 0.046 450 1457 Average
Below average medium possible neutral
Gudebrod 6/0 Polyester 6/0 143 0.058 920 2466 Strong
Average
Gudebrod 10/0 Mono Mono 10/0 50 0.152 1219 329 Very strong
Below average none none very smooth
Lagartun   Polyester   150 0.048 907 3125 Strong
Above average
Lagartun XX Strong GSP   50
  high good smooth
Lagartun XX Strong GSP   75
  high good smooth
Lagartun XX Strong GSP   100
  high good smooth
Lagartun XX Strong GSP   130
  high good smooth
Lagartun   Polyester   74 0.030 454 2467 Average
Average
Lagartun   Polyester   95 0.036 482 2639 Average
Average
Montana Fly Co 8/0 Nylon 8/0 72 0.036 397 2000 Weak
Average
Montana Fly Co 6/0 Nylon 6/0 110 0.051 652 2157 Average
Average
Montana Fly Co 3/0 Nylon 3/0 135 0.056 709 2411 Strong
Average
Montana Fly Co   Nylon   350 0.081 1927 4321 Very strong
Strong
Orvis 12/0 Polyester 12/0   0.050
  medium difficult neutral
Orvis 8/0 Polyester 8/0   0.055
  medium difficult neutral
Orvis 6/0 Polyester 6/0   0.060
  medium difficult neutral
Pearsall Silk Silk   140

Roman Moser Carbon FIber Tying Thread ? 3/0

Roman Moser RM - Pre waxed Tying Thread Midge Polyester 10/0

Roman Moser RM - Pre Waxed Tying Thread Standard Polyester 6/0

Roman Moser Power Silk 1/0 (strong) Dyneema Thread GSP 1/0     1814   Very strong
  high good smooth
Roman Moser Power Silk 10/0 (fine) Dyneema Thread GSP 8/0 55 0.033 1077 1667 Strong
Strong high good smooth
Roman Moser Power Silk 5/0 (medium) Dyneema Thread GSP 6/0 115 0.033 2041 3485 Very strong
Extremely strong high good smooth
RST Dynacord (Dynema) GSP   150 0.135 3430 1111 Extremely strong
Strong high good smooth
Semperfli 6/0 Fly Tying Thread Polyester 6/0

Semperfli Nano Silk Ultra Fine 30D 18/0 GSP 18/0 30   1140   Strong
  high good smooth
Semperfli Nano Silk 50D 12/0 GSP 12/0 50   1900   Very strong
  high good smooth
Semperfli Nano Silk Predator 100D 6/0 GSP 6/0 100   3800   Extremely strong
  high good smooth
Semperfli 8/0 Tying Thread Polyester 8/0

Semperfli Nano Silk Predator 200D 3/0 GSP 3/0 200   7600   Extremely strong
  high good smooth
Sparton Macro Polyester   225   1360   Very strong

Sparton Micro Polyester 8/0 72   566   Average

Sparton Professional Polyester 4/0 135   992   Strong

Sparton Fluorescent Polyester   162   907   Strong

UNI UNI-Cord GSP 7/0 100 0.036   2778
  high good smooth
UNI UNI-Thread 3/0 Polyester 3/0 220   907   Strong
  medium difficult neutral
UNI UNI-Nylon 210 Nylon   210 0.051 1445 4118 Very strong
Strong high good smooth
UNI Kevlar Kevlar 3/0 200   3798   Extremely strong
  high difficult coarse
UNI UNI-Cord GSP 8/0 75 0.036 1928 2083 Very strong
Very strong high good smooth
UNI UNI-Thread 1/0 Neon Fluorescent Polyester 1/0 234   992   Strong

UNI UNI-Thread A+ Polyester   315   1360   Very strong

UNI UNI-Clear Mono Size 4m Mono 3/0
  none none very smooth
UNI UNI-Cord GSP 12/0 50 0.023 1105 2174 Strong
Very strong high good smooth
UNI Caenis Nylon   20 0.043 85 465 Very weak
Very weak
UNI Trico Nylon 17/0 40 0.051 142 784 Very weak
Very weak
UNI UNI-Thread 8/0 Polyester 8/0 72 0.051 450 1412 Average
Below average medium difficult neutral
UNI UNI-Nylon 70 Nylon   70 0.074 822 946 Strong
Average high good smooth
UNI UNI-Thread 6/0 Polyester 6/0 135 0.041 930 3293 Strong
Above average medium difficult neutral
UNI BigFly Polyester   400 0.089 2381 4494 Extremely strong
Strong low difficult neutral
Veevus G20 30D GSP 18/0 30 0.025 652 1200 Average
Strong high good smooth
Veevus G20 100D GSP   100 0.033   3030
  high good smooth
Veevus 16/0 Polyester 16/0 50 0.038 430 1316 Average
Average high good neutral
Veevus G20 150D GSP   150 0.042 3742 3571 Extremely strong
Extremely strong high good smooth
Veevus 12/0 Polyester 12/0 70 0.047 530 1489 Average
Average high good neutral
Veevus 14/0 Polyester 14/0 70 0.049 520 1429 Average
Average high good neutral
Veevus G20 200D GSP   200 0.050   4000
  high good smooth
Veevus 10/0 Polyester 10/0 110 0.055 800 2000 Strong
Average high good neutral
Veevus 8/0 Polyester 8/0 110 0.059 1000 1864 Strong
Average high good neutral
Veevus 6/0 Polyester 6/0 110 0.065 1000 1692 Strong
Average high good neutral
Veevus Monofil Thread Mono     0.100
  none none very smooth
Veevus Monofil Thread Mono     0.200
  none none very smooth
Wapsi GSP 100 GSP   100 0.030 3147 3333 Extremely strong
Extremely strong high good smooth
Wapsi UTC 210 Nylon   210 0.081 1350 2593 Very strong
Average high good smooth
Wapsi GSP 130 GSP   130 0.051 2948 2549 Extremely strong
Very strong high good smooth
Wapsi UTC Ultra Thread Kevlar Kevlar   200
  medium difficult coarse
Wapsi UTC Mono Fine Mono     0.010
  none none very smooth
Wapsi UTC Mono Medium Mono     0.015
  none none very smooth
Wapsi UTC Mono Thick Mono     0.020
  none none very smooth
Wapsi GSP 50 GSP   50 0.020 1048 2500 Strong
Very strong high good smooth
Wapsi UTC 70 Nylon   70 0.028 450 2500 Average
Average high good smooth
Wapsi UTC 140 Nylon   140 0.041 900 3415 Strong
Above average high good smooth
Wapsi UTC 280 Nylon   280 0.069 1800 4058 Very strong
Strong high good smooth

Material

Mono is monofilament nylon. Silk is natural silk. The rest are synthetic multifilament threads produced using different methods. Two threads made from the same material can be very diferent.

Aught

The most common way to indicate thickness. Not a physical standard. Larger number means thinner thread, so 8/0 is thinner than 6/0.

Denier

The weight in grams of 9000 meters of thread. A physical standard used in the textile industry, but not an indication of thickness or strength.

Dia

Diameter in millimeters (mm) or thousands of inches (.000"). As specified by the manufaturer or measured by me or others.

Breaking

The breaking strength or test of the thread in grams (g) or ounces (oz). The number is the highest found if values from different sources differ.

Relative dia

A visual indication of the relative thickness of the thread compared to others. Not to measure in any way! Just a visualization.

Denier/mm

A simple calculation of what the Denier would be if the thread was 1 millimeter thick, and a way to compare the Deniers for the different threads. Ideally this number should be the same for threads made from the same material, but the numbers clearly indicate that the Denier number does not help us much in comparing even almost identical threads. Denier and thickness are NOT correlated.

Denier and thickness are NOT correlated.

Absolute strength*

The absolute breaking strength of the thread compared to all other threads and not taking diameter or material into consideration..

Relative strength*

An indication of the relative strength of the thread compared to its diameter and the other threads. Not an absolute measurement! Thin threads can be as relatively strong as thick ones. The numbers indicate breaking strength in relation to diameter.

Flatability **

The thread's ability to flatten when tied in. Sometimes requires the thread to be untwisted.

Splitability **

The thread's ability to split when used for the split thread dubbing technique.

Smoothness **

How slippery or smooth the thread is against the hook shank or materials. Its ability to "grip" materials.

*

The textual strength indications are based on calculations and data comparisons and the groups are defined by the me. They are objective, based on numbers, but you may disagree with my scale.

**

These properties are assessed by me based on threads that I have tied with. I have only added data for unseen mono threads, which are basically all very smooth, round and can't be split.

See the main article for more on tying threads.

Articles in this series

Work in progress

This article on tying threads and all the data that is part of it is work in progress and will be updated as soon as I get more or better information on the various threads.
If you have things to add, comments or corrections, feel free to contact me on martin@globalflyfisher.com. You can also leave a comment to the article, and I will see it and respond if required.
I welcome contact from tying thread manufacturers with information, specifications, remarks or corrections - even criticism. The more the better!
